Pin Lock Ring Allround System Layher Access Ringlock Tower Scaffolding

Pin Lock Ring Allround System Layher Access Ringlock Tower Scaffolding

Description of Ringlock Scaffold Wellmade Scaffold produces all types of ringlock scaffolding include layher allround sc
SHARE

Description

Basic Info
Model NO. WM-RS
Erection Position External Scaffolding
Move Method Lifting Bridge
Scaffolding Part Type Scaffolding Frames
Construction Properties Building Scaffold
Usage Building
Standard En BS1139
Surface Hot DIP Galvanized
Service OEM Is Available
Transport Package Steel Pallets
Specification CE, EN74, BS1139, SGS, AS1576
Trademark WM Scaffold
Origin China
HS Code 7308400000
Production Capacity 500 Containers/Month
Product Description
Description of Ringlock Scaffold

Wellmade Scaffold produces all types of ringlock scaffolding include layher allround scaffolding types, at-pac types ringlock scaffolding, pin lock scaffold, New Zealand Types of Ringlock Scaffolding, Chile type multidirectional scaffolding etc.All types of ringlock scaffolding are made from OD48.3mm scaffold tube for normal duty and OD60.3mm scaffold tube for shoring heavy duty. Ringlock scaffolding components:1) Ringlock standards: Verticals with rosette rings on and coupling pin as spigot to connect different standards in construction. Different types of ringlock standards has different rosette shape. Ringlock standard vertical tube should be S355(Q345) higher strength steel grade. Rosette rings can be S355 or S235. Pin Lock Scaffold and At-pac type ringlock scaffold rosette rings should be in S355 and annealed that good for cold weather. Shoring scaffolding ringlock system vertical tube should be made from 60mm diameter scaffolding tube. 2) Ringlock Ledger Horizontals: Ringlock Ledgers are made from 48.3mm scaffold tube with cast steel ledger ends and wedge pins to lock and connect ringlock standards. Different ringlock types has different ledger ends too. There are O ledger and U ledger in layher scaffolding and new zealand type ringlock scaffolding. U ledger are made from U profile with legder ends an wedge pins. 3) Ringlock Intermediate Transom: Ringlock transom is made from 48.3mm diameter scaffold tube with C pressing and wedge pins on to give a support for ringlock platform in middle. 4) Ringlock Diagonal brace: Ringlock Diagonal brace is made from OD48.3mm or OD42mm scaffolding pipe according to different clients requirement. There are vertical diagonal and horizontal diagonal for ringlock scaffolding system.5) Adjustable screw jack base: adjutable base plate can be in E-galvanized or hot dip galvaized. Adjustable range for screw jack base can be 0-1000mm customized. The Jack nut for jack base can be normal duty and heavy duty. Jack base type can be drop forged or casted. There are square threaded and round threaded jack base. Round threaded jack base is more stronger. 6) Ringlock Side bracket: ringlock side bracked can be fixed size or ajdustable size. 7) Ringlock truss ledgers: Truss ledgers for ringlock scaffolding are made from 48.3mm scaffold tube with casted steel ledger ends and wedge pins which is a type of stronger ledgers for access. 8) Ringlock scaffolding lattice girders:Ringlock scaffolding lattice girders can be in standard size of 5.17m, 6.14m, 7.71m in hot dip galvanized with ledger ends and wedge pins. 9) Ringlock scffolding steel planks:ringlock scaffolding steel planks include 230x67mm with 4 hooks, 240x67mm with dog ear hooks at-pac type, 320mm and 300mm steel planks. Steel planks hooks are different for O ledger and u ledger in ringlock scaffolding system. 10) ringlock base collar:ringlock scaffolding base collar is a components for bases of ringlock system. It is made from 48.3mm scaffold tube and OD57mm outer tube with one ring on. There are different height of base collar according to different system and clients request. 11) Ringlock scaffolding stairs: There are steel scaffolding stairs and aluminium stairs for ringlock scaffolding system for access scaffolding.Usage:Ringlock scaffolding is one of the most popular scaffolding modular system. It is used not only for construction building, concrete formwork and shuttering forming support, but also used for onshore and offshore project by its quick erect, modular, fast and economy,durable. Quality Control and Service:Wellmade scaffold ringlock scaffolding are tested and safety according to Europe Standard En12810 as well as En12811. Wellmade scaffold is a leading scaffolding manufacturer exporter in China,famous OEM factory for peri formwork,layher scaffolding ,with 50,000m2 auto production lines, ISO9001 management, independent testing house and 24 hours quality control system, offers not only high quality scaffolding products, but also good price, door to door delivery services, customized mark and stickers. Get more information for ringlock scaffolding system from wellmade scaffold Get scaffolding solutions, scaffolding consulting and calculation, scaffolding prices and door to door deliver from wellmade scaffold by mail.
